HARVIA SENLOG COMBI

OVERVIEW SPECIFICATIONS ADVANTAGES GALLERY

The Harvia Senlog Combi CF9C features a simple stylish design that provides an easy-to-use interface for controlling the sauna heater. You can install the panel in any dry space. With Harvia Senlog, in addition to the steam generator, you can also adjust the lighting and ventilation system of the steam room.

Choose Senlog - Harvia's pioneering spirit of technology.

(For combi sauna heaters up to 9kW)

SPECIFICATIONS

Power kW	9
Weight.kg	0,6
Dimensions depth cm	5,8
Dimensions width cm	18,5
Dimensions height cm	14,6
Temperature adjustment range	40–110 °C
Pre-setting time adjustment range	6h
Supply voltage	400V ~ 3N AC
Max. load	9 kW

ADVANTAGES

Supply voltage: 400V ~ 3N AC
Max. load. 9 kW
Heater supply load: U, V, W 3 kW/ Phase
Operating voltage of evaporator: W1 3kW
Note: W and W1 alternate when the heater and evaporator controls are active.
Safety level: IPX3, installed outside sauna and restroom, in dry room.
Pre-setting time adjustment range: 6 h
Temperature adjustment range: 40 oC–110 oC
Sensor: temperature sensor, over temperature protection.
Lighting and ventilation connections: Max.100 W
The humidity setting depends on the setting humidity: RH/ rF 0% – 100% when the sauna is at maximum temperature.
