The Harvia CX260 control panel regulates the electric sauna heater up to 22-34kW, equipped with a 16-25A circuit breaker. With the help of the clock you can program the central setting of the steam room or the steam generator can turn on and off automatically at the time you desire. The maximum operating time of the steam generator can be limited to 6, 12 or 18 hours.
The Harvia CX260-20 has many remote control features.
(For sauna machines with a maximum capacity of 20 - 34 kW)
| Weight kg | 3,6 – 3,9 |
| Dimensions depth cm | 7 |
| Dimensions width cm | 25 |
| Dimensions height cm | 22,3 |
| Adjustable temperature min-max | 40-110 °C |
| Supply voltage 3-phase | 380 – 415 V~3 N |
| Fuse A | 3 x 35A |
| Group fuse, F1, F2 | 3 x 35 – 50A |
| Max display | 125 °C |
| Maximum output | 22 – 34 kW |
